UBCO 2X2 Xtreme Duty Single Rack

Capable of hauling up to 150 lbs per tray, The XD rack pushes the boundaries of what’s possible with an all aluminum rack, allowing you to carry virtually any bike, any where.

The XD rack features the same anti-wobble hitch bar that is used on all our aluminum racks to guarantee a solid connection to your vehicle. From there, we've beefed up virtually every part of the rack. Check out the list of features below!

Features

Fits 2” receiver
Compatible with XD Add-Ons (sold separately) so you can use your existing Quik Rack Add-ons, from bike trays to cargo to lights and accessories
Total carry capacity with XD Add-Ons of up to 345 lbs (150 lbs first bike spot max)
Road rating: Pavement, Gravel, and Off-road
Vehicle rating: Passenger Vehicle and RV/Travel Trailer (2 Spots)
Double Bent Arms add lateral stiffness
Xtreme Duty Wheel Chock* (sold separately) reduces steer tube rotation minimizing bike movement
Lock-in Pivot Beam reduces virtually all play in the pivot for extra rigidity
Spring Pin allows easy raising and lowering of an unloaded rack for vehicle access
New Glide Bar Ratcheting system provides a robust, positive engagement of the ratchet
Add up to one XD Add-On to carry an additional bike (up to 120 lbs)
V Style Ramp (sold separately) is easier to use than ever; the XD bent arms fold all the way down to allow easy loading in seconds
Slot for standard hitch pin holes
Fits 16” - 29” wheels, up to 5.25” wide
Accommodates up to 57” wheelbase
Hitch bar has built-in anti-wobble mechanism
Tilt and folding mechanism for smaller footprint
Rack arms close to secure tires without touching the frame
All rack parts anodized, except a powder coat finish on the tray
Shipping Weight: Hitch Assembly Box: 19 lbs / Tray Assembly Box: 30 lbs
What's included

2″ Xtreme Duty Single
Slotted Hitch Bar Lock
Instructions
